Applicable Materials of  YD-F3020KJ UV Flatbed Inkjet Printer:

1. High speed uv led flatbed printer can print on almost all flat materials, including glass, ceramic tile, wood, aluminum, acrylic sheet, PVC sheet, EVA, fora board, corrugated board, etc.

Advanced Features:

1. • UV Flatbed Inkjet Printer adopts high speed industrial Kyocera inkjet print head.
2. • ultra large format 3.0×2.0M maximum print size.
3. • multi-color printing, able to print CMYKW and varnish, 3D, embossed, glossy effect achievable.
4. • wide application, can print on almost all flat materials.
5. • simple printing process, direct print on surface technology, suitable for small batch and mass production.
6. • fast and delicate LED-UV ink curing.
7. • long-life parts and machine, delivering excellent performance.
8. • …

9.


    Specifications

   Printer Model	YD-F3020KJ
   Print Size	3000 × 2000 mm (9.8 × 6.6 ft)
   Printhead	Kyocera KJ4A grey level Piezo print head
   Printhead Quantity	2-8 pcs (4-7 colors optional)
   Print Resolution	635 × 2400 DPI
   Material Thickness	Up to 100mm (4in)
   Material Type	Rigid and flexible material
   Printing Material	Glass, acrylic, wood, ceramic, metal, PVC, corrugated board, plastic, etc.
   Ink Color	C, M, Y, K, Lc, Lm, White ink
   Ink Type	Original imported UV curable ink
   Interface Mode	High Speed USB
   UV Curing System	LED UV lamp
   RIP Software	Onyx
   Color Management	International standard ICC
   Input Format	PDF, JPEG, TIFF, EPS, AI
   Printer Weight	1750KG
   Printer Size	4996mm[L] × 2800mm[W] × 1360mm[H] (16.4ft×9.2ft×4.5ft)
   Package Size	5250mm[L] × 3000mm[W] × 1680mm[H] (17.2ft×9.8ft×5.5ft)
   Power Requirement	220V/AC(±10%), 50/60 HZ, 6KW
   Working Environment	Separate, little sunlight, ventilated workshop, Temperature: 18℃~30℃（64℉~86℉); Humidity: 30%~70% (Non-condensing); Ventilation equipment: suggest overhead exhaust fan, displacement 600cfm.
